SPECIFICATIONS

APP: Tuya Smart App

Battery: 4200 Mah Lithium Battery

Brand Name: Atopkoo

Data Storage Options: Cloud

Door Type: Wood Door,Steel Door,Stainless Steel Door,Aluminum Door,Brass Door

Door thickness: 40-120mm

Emergency Power Supply: Type-C Interface

Lock Cylinder Security Grade: Grade C

Material: Aluminium Alloy,Alluminum Alloy

Model Number: OD-F7

Mortise: 6068/240*24mm

Network: Wi-Fi

Optional features: Face id/Cat's eye

Place of Origin: Guangdong, China

Smart App: Tuya App

Suitable for Doors: Wooden Door+steal Door

Unlock way: Face+APP+Vena digitalis+Password+IC card+Key

Warranty: 2years

Recommend Products

Features

1、 8 ways to unlock: Tuay APP Access, Fingerprint Unlock, PIN Code, Card, Mechanical Key Unlock.Living biometric fingerprint reader gives you the best security experience ;

3D Face recognition;

Remote Cat's eye; 2.Compatible with various mortise to fit 99% doors. Can match: single latch60/70, European mortise 6068/ 6085/ 6072 / 5572 ; 3. Material:Aluminum Alloy 4. Convenient APP management system, you can manage your smart lock anytime and anywhere; 5. You can manage a large number of locks with just one phone; 6. Simple Door Handle settings, suitable for various scenarios; 7. Multi-level administrator settings to help you better manage your smart buildings; 8. Query unlock records anytime and anywhere, the first time to know your home security; 9. The compact size fits all wooden doors and metal doors; 9. can set for "alway open mode" at different time,and open the door directly after setting. 10. Emergency powersupply in case of lost power; 11. can be used as right handle or left handle,no right or left difference, just pressing handle to open the door. 12.We can customize production according to your requirements,OEM/ODM;

Specification

Brand Name	ATOPKOO/OEM
Model Number	OD-F7
Material	aluminum alloy
New Features	3D Face recognition+Remote Cat's eye
Colour	Silver Grey/Customizable
Unlock Method	Face +App+Fingerprint+Password+Card+Key
Fingerprint capacity	100Pcs
Password capacity	100Pcs
Network	WiFi/Zigbee
Data Storage Options	Cloud
Door thickness	45-120mm
Power supply	4200 Mah Lithium Battery
Mortise	6068 / 3585/ 4585/ 6085/ 6072 / 5572 etc.
Warranty	1 Year
Weight	3KG
Certification	CE
Door Type	Wood door, Security door, safety door, room door, metal doors, armored doors, composite doors

Products Description

Company Profile

Shenzhen yimeida lock industry co.,ltd

Shenzhen yimeida lock industry co.,ltd,who has been helping to make access smart,simple and safe in thepast 8 years.During so many years development,we are dedicated to producethe smart lockd and Access Control Terminal(OEM/ODM Fingerprint door lock,Password door lock,Rfid card door lock,App door lock,Face recognition door lock),to make it become one of our commonlife uses with steady quality which has passed CE certificates.Thus,we welcome customers to discuss with us about design, software integrationand distributor.We would love you to be part of our new story.

Product packaging

Corrugated paper+pearl cotton tightly wrapped

20pes/CTN,Corrugated paper box ，Carefully inspect before shipment

FAQ

Q: How can I check the latest prices?

A: We've always got special offers for you. With so many great deals, you could find that lots of products are cheaper than you thought!

Q:How to open the lock if the card is not work or there is something wrong with the electronic part?

A: Each lock are equipped with 2 mechanical keys, you can open door with those keys.

Q:What should do when battery is run out?

A: There has low battery alarm. You can still use the card open about 200 times when it alarms. If it is out of power, you can use backup key to open the door or use power bank to charge it to open and then change the batteries then.

Q:If logo print is available?

A: Yes, we can help to print your logo on the lock and OEM/ODM service are welcome.

Q:What's the delivery time?

A: Sample within 2 workdays, quantity order takes about 7~15 days.

Q:How is your production ability?

A: We have 3 production lines, monthly production capacity is about 15,000 pieces.

Q:What is your MOQ?

A: Our MOQ is 1 piece, welcome all kinds of customers.

Q:Could you help with my designed products?

A: Sure. We offer both OEM&ODM products.

Q:How can you make a difference from other suppliers?

A: We have enjoyed more than 7 years of rapid development together with our customers.We know our customers' need as well as the market's developing trend.And we have our own professional installation team, fully understand any problems happens during the installation of the door lock,and we have the way to solve any problems that happens in the installation or use.
